Seal and Label Vision Inspection System - VisioLine®
The VisioLine® is an integrated vision system for inspecting food packaging in thermoformers and traysealers.
Integrated Vision System for Food Packaging Inspection
VisioLine® is a standardized vision inspection system for integration in thermoformers.
By implementing the quality control of food packaging within the thermoforming machine, valuable footprint on the factory floor is saved.
Additionally, VisioLine® is the perfect solution for inspecting packages of thin, flexible foil, as seal inspection usually must be performed before the punching process to achieve reliable failure detection.
• Seal and label inspection of food packs before the punching process
• High-speed inspection - up to 10 m/min
• Quick and easy format change
• Inspection results are delivered to an external ejection system
• Effective real-time overview of quality data and production performance
• Industry 4.0-ready with multiple comm. protocols and MES/ERP connectivity
• Cloud-based backup & Production Intelligence tool
Performance
Max. peak indexing speed: 1200 mm/s
Max. throughput: 200 packs or 10m/min
Formats supported: All
Vision Components
Cameras: 2-5x GigE Line Scan
Computing System
Processing system: Industrial PC
Operating system: Windows 10 IOT Enterprise LTSC
Interface: Gigabit Ethernet and digital I/O - separate ethernet connection for machine network is optional
Comm. protocol: OPC UA and REST API
HMI: 15,6” full HD multi-touch panel
Power Requirements
Power Supply: 230 VAC / 5A / 50 Hz
Mechanical Specifications
Dimensions: Length: 550 mm Height: 1067/720 mm Width: Adjustable to fit packaging machine.
Material: Stainless steel AISI 304
Enclosure Rating: Electrical cabinet IP66 Bottom Camera housing IP 66 Main housing no enclosure rating
Ejection System: Not included - integrates with external ejection unit.
TriVision’s food inspection systems inspect different aspects of different foods as our technology has a wide application when it comes to food inspection. Hence, our systems work as efficient quality control solutions for many sectors within the food industry such as seafood, dairy, meats, prepared foods, and confectionary.
The wide application of our systems also means that we can inspect specifically what is important to manufacturers and their customers. Besides ensuring that all bad food products are rejected from the processing line, our systems' allow manufacturers to obtain data and learn from all inspections made to optimize the processing.
